[Feature]： |
|
[Super Mini Size and Easy Protable] |
|
[Light&Convenient Plug In] |
|
[Application]: |
|
[Digital
Camera] |
|
[CD-ROM HUB ADSL AP] |
|
[Communication
Terminals] |
|
[Tester
Machine] |
|
[Any Protable Device or Machine] |
|
[Input/Output Specifications]: |
|
[Input
Voltage]:
AC
100-240V,50/60Hz |
|
[Range
Voltage]:
AC
90--264V,47/63Hz |
|
[Output
Power]:
45W |
|
[Output
Voltage]:
12V-24V |
|
[Over
Voltage Protection]:
120%min |
|
[Over
Current Protection]:
120%min |
|
[Short
Protection]:
Auto
Recovery |
|
[Load
Regulation]:
±5% |
|
[General
Specifications]: |
|
[Operating
Temperature]:
0~40℃ |
|
[Storage
Temperature]:
-20~85℃ |
|
[Operating
Relative Humidity]:
5~95%RH |
|
[Withstanding
Voltage]:
AC
3000V(Min),5mA(Max) |
|
[Insulation
Resistance]:
DC
500V 100MΩ(Min) |
|
[Safety]: UL/cUL PSE GS
CE CB FCC BSMI |
